N80/N80M AM Anti-theft device
The SSLT N80/N80M series AM acrylic anti-theft system is mainly used for anti-theft of goods in retail stores. It uses imported acrylic material, which is crystal clear, beautiful and simple. The maximum distance between channels can reach a protection distance of 2.6 meters.
Configuration and usage:
Main antenna: A transmitting and receiving integrated antenna with independent control function.
Sub antenna: It also has detection function and alarm function.
Configuration 1: One main antenna can carry one secondary antenna, forming two integrated antennas for transmitting and receiving.
Configuration 2: One main antenna can carry up to two sub antennas, forming three integrated antennas for transmitting and receiving
Specification: 1535 * 400 * 25 mm Bottom shell width: 140mm
Debugging method: N80: Remote control debugging
N80M: Mobile app software debugging, motherboard comes with WIFI module, no connection required
Parameter specifications:
Main inputs: 110-120VAc/220-240VAc, 1A 50-60HZ
Working frequency: 58KHZ
Transmission pulse duration: 1.6ms
Packaging specifications (single piece): 1600 * 450 * 150mm
Weight: 18.5kg
Detection range (within the channel): DR soft label: 140-160CM; Hard label: 180-260CM
