Imported acrylic hollow design; The system has high detection rate, good stability, strong anti-interference ability, and can be expanded into an EM+RFID dual system; The system is embedded with reserved inbound and outbound passenger flow modules; This product is widely used in smart library venues both domestically and internationally.

Functional features:

1. Design concept: Eight hole acrylic hollow appearance design, symbolizing reunion;
2. Detection method: The system can quickly identify the EM magnetic strip labels pasted on the data and trigger an audible and visual alarm, with customizable alarm lights;
3. Anti interference ability: The system has software self control and self checking function, which can effectively filter out interference issues with laptops and high-power mobile phones;
4. Stability: Adopting digital DMPD technology, the system is more stable;
5. Linkage: The system can be optionally equipped with reserved interfaces for linkage with gate machines, monitoring probes, and big data analysis:

(1) Realize the alarm of books that have not been processed through the corresponding book detection door, and simultaneously close the gate of the corresponding channel through linkage;
(2) Implement alarm image capture function, and obtain evidence for theft behavior through alarm nodes and images in the background;
(3) Implement data on the alarm time and frequency of each channel, upload data through the display screen or API interface for statistical analysis;

6. Independence: the optional distribution channel independent alarm function makes the anti-theft management more intelligent;
7. Statistical function:
(1) Optional host display system for daily passenger flow statistics (regardless of entry and exit);
(2) Optional host or antenna with built-in LED in and out passenger flow accumulation system;
(3) Optional external large screen display functions such as number of visitors, number of visitors, total number of visitors, number of alarms, and book borrowing status;
(2) Optional LAN PC can be equipped to enable managers to view each floor, each channel entry and exit, and count the number of alarms, as well as accumulate the total entry and exit, total number of alarms, and number of people in the museum;
8. The system is equipped with an infrared control to activate. When a reader is detected passing, it starts to detect and remains in standby mode when no one is passing, achieving energy-saving and reducing the possibility of false alarms;
9. Equipped with API interface standard protocol, it can easily connect with third parties to achieve data upload;
10. Safety: EU CE, EMC electromagnetic compatibility certification, human body injury free certification, and electronic inspection certification of the Ministry of Public Security of China;
11. Optional built-in RFID antenna module for easy upgrade to an EM+RFID dual system in the future without replacing the EM antenna;

Technical parameters:

1. Working frequency: 1KHZ
2. Production material: pure imported acrylic
3. External dimensions: 65 * 2.5 * 180cm
4. Detection range: single channel: height: 5-185cm, width: 100-110cm; Dual channel height: 5-185cm, width: 200-220cm
5. Alarm method: audible and visual alarm, customizable with different alarm colors
6. Signal processing: Digital DMPD technology, DSP multiple filtering technology
7. Production material: pure imported acrylic material, without deformation, discoloration, crystal clear and transparent, with strong wear resistance
8. Time between failures ≥ 80000 hours
9. Antenna power: 3.6W-5W
10. Working voltage: AC: 220V ± 20%, 50Hz
11. Overall output power: 35W
