1. Number of sterilization books: ≥12 copies at a time

2. Book placement method: all vertical (easy to use, better blowing effect).

3. Cross-flow double fan design, good blowing effect and low noise.

4. Install the leakage protection device to effectively protect the equipment from electric shock and electric shock when the equipment has a leakage fault. .

Functional requirements:

(1) The machine provides users to operate the book sterilization operation by themselves.

(2) Using ultraviolet sterilization technology, the total number of lamps is ≥14 groups (single operation room) to ensure the sterilization effect of each angle (☆)

(3) Provides the function of cyclone-type flipping pages one by one to achieve the sterilization effect of the cover and the inner pages at the same time.

(4) Using high-quality filters, it can collect allergenic elements in the environment such as fine dust and bacteria, and does not derive harmful substances such as ozone or carbon dioxide.

(5) There is a see-through window on the machine (effectively preventing ultraviolet light from hurting readers' eyes), allowing readers to watch the progress of sterilization operations at any time.

(6) With humanized operation interface design (eg: one touch), it is convenient for users to operate.

(7) The sterilization operation shall not leave scratches or any traces of damage on the cover or inner pages of the book.

(8) The sterilization time prompt adopts the design of colorful seven-color lights, the sterilization time is adjustable, and the adjusted sterilization time must be synchronized with the work of the colorful seven-color lights (☆).

(9) The equipment has relevant consumables replacement indicators.

(10) Built-in 10-inch display + 4.3-inch touch screen, clear interface, convenient for readers to use (☆).

(11) It has the function of overhauling the whole machine to better prolong the service life of the equipment (☆).

(12) The internal space size of the operating room is ≥600*510*480mm (length*width*height), which can sterilize books of large size such as art, and provide corresponding supporting documents when bidding.

(13) The core electronic control system adopts a mature and stable PLC design, and each set of equipment is provided with a set of corresponding PLC electric boards.
